Tableware Industry – CERADECORS

of

Ceramic Decoration Colors and Materials

We offer a wide variety of brilliant decorating colors for onglaze, inglaze and underglaze applications for ceramics and various substrates including low toxic metal release, lead-free and cadmium-free colors to meet the current exacting performance demands of the ceramic industry.

Tableware

InstantColor Stains for Sanitaryware

Ceradecor industrial ceramic pigments are designed to color all types of special glazes and bodies used for sanitaryware. Our InstantColor ceramic pigment stains offer 25 shades that result in an infinite number of colors that exhibit high purity, intensity, and brilliance within the complete color spectrum. Significant cost savings can be achieved as colors are easily adjusted right in the barrel.

InstantColor stains are developed to meet the specific technical and firing requirements of the sanitaryware industry. These include being fired for several hours at a temperature higher than 1200 °C and for the color to remain true and constant. They are also capable of being fired a second time at high temperatures without any deterioration of color and surface properties. This enables sanitaryware manufactures to perform an additional repair firing or a decorating firing process, as needed.

Proven Quality

All the ceramic stains in our InstantColor range consist of extremely fine, uniformly minute particles that are dissolved instantly.

These colors are readily dispersed in standard slurries, requiring no ball milling as practically all primary grains are smaller than 32 μm with no coarse agglomerates that need grinding for slurry preparation.

from

Custom Color Mixing

We offer a standard mixing palette of colors which gives our customers the flexibility of tailoring mixings and color matches onsite.

to

INSTANTCOLOR PLUS STAINS FOR SANITARYWARE PROPERTIES AND FIRING CONDITIONS

Pigment	System	Color	Crystal Structure	Tmax/°C	Firing Conditions
210 950	Cr-Al	Olive Green	Corund	1400	ox./red
210 946	Co-Al-Cr	Green Blue	Spinel	1400	ox./red.
220 942	Zr-Si-V	Turquoise	Zircon	1350	ox./red.
220 944	Co-Al	Blue	Spinel	1450	ox./red.
220 946	Co-Si	Cobalt Blue	Olivine	1450	ox./red.
230 942	Zr-Si-Cd-S-Se	Brilliant Orange	Zircon	1350	ox./red.
230 944	Zr-V	Havanna	Baddeleyite	1400	ox./red.
230 946	Zr-Si-Pr	Intense Yellow	Zircon	1250	ox./slightly red.
249 942	Co-Ni-Fe-C	Black	Spinel	1300	ox./red.
259 959^*	Zr-Si-Co-Ni	Blue Grey	Zircon	1350	ox./slightly red.
260 946	Zn-Al-Cr-Fe	Light Brown	Spinel	1300	ox./red.
270 944	Zr-Si-Cd-S-Se	Intense Red	Zircon	1350	ox./red.
260 952	Zn-Cr-Fe	Red Brown	Spinel	1300	ox./red.
270 946	Zr-Si-Fe	Coral	Zircon	1250	ox.

to

GLAZE SYSTEM COMPATIBILITY

Pigment	R₂O	MgO	CaO	ZnO	PbO	SnO₂	B₂O₃	ZrO₂	Color addition for Color Examples
Pigment	R₂O	MgO	CaO	ZnO	PbO	SnO₂	B₂O₃	ZrO₂	transp. glaze	opaque glaze
210 946		unsuitable combinations		unsuitable combinations		unsuitable combinations			2 % in A	2 % in B
220 942	unsuitable combinations				unsuitable combinations			well suitable combinations	5 % in A	2 % in B
220 944				well suitable combinations					2 % in A	2 % in B
220 946				well suitable combinations					2 % in A	2 % in B
230 942	unsuitable combinations		well suitable combinations	well suitable combinations	well suitable combinations		well suitable combinations		5 % in A	2 % in B
230 944			unsuitable combinations	unsuitable combinations	unsuitable combinations		unsuitable combinations		5 % in A	2 % in B
230 946	unsuitable combinations				unsuitable combinations			well suitable combinations	5 % in A	2 % in B
249 942									5 % in A	2 % in C
259 959^*				unsuitable combinations	unsuitable combinations			well suitable combinations	5 % in A	2 % in B
260 946				well suitable combinations				well suitable combinations	5 % in A	5 % in D
260 952				well suitable combinations				well suitable combinations	5 % in A	5 % in D
270 944	unsuitable combinations		well suitable combinations	well suitable combinations	well suitable combinations		well suitable combinations		5 % in A	5 % in C
270 946	unsuitable combinations				unsuitable combinations			well suitable combinations	5 % in A	2 % in B

CeraDecor provides complete custom color matching services to help our customers develop new colors and finishes to meet specific industry standards and/or unique customer needs. In addition to matching colors, CeraDecor can provide formulas to customers using the base/tint system.

Precise color matching can be achieved using our internal extensive database and color matching expertise. All colors are matched to defined reference samples to ensure exact match and consistent color reproduction from batch to batch.

APPLICATIONS TECHNOLOGY SUPPORT

Custom
Formulations

We work closely with our customers to co-innovate and develop customized high-performing and economical coloring solutions based on application requirements and operational processing needs, including tailored formulations and formulation guides.

Toll
Manufacturing

For customers who need additional manufacturing capabilities, we provide a full range of manufacturing capacities, from pilot runs to full-scale production.

in

Custom Color Matching

CeraDecor provides complete regional custom color matching, blending and pasting services to help our customers develop new color shades and coatings according to specific requirements including production methods and desired finishes.

Precise color matching can be achieved using our internal extensive database and color matching expertise. All colors are matched to defined reference samples to ensure exact and consistent color reproduction from batch to batch.

of

Ceramic Decoration Colors and Materials

Tableware

15 Series Opaque Glass Colors for Decal Application

31 Series Transparent Glass Colors for Decal Application

33 Series New Low Fusing Glass Colors for Glass Decal Application

64 Series Low Metal Release Onglaze Colors

721 Series Low Metal Release Resistant Onglaze Colors (CHINA)

726 Series Four-Color Printing Low Metal Release Onglaze Colors (CHINA)

731 Series Lead-Free Onglaze Metallic Colors (CHINA)

732 Series Lead-Free Interference Onglaze Colors (CHINA)

741 Series Lead-Free Inglaze Colors (CHINA)

781 Series Lead-Free Onglaze Colors (CHINA)

Anti-Blocking Agents for Ceramic Decoration

Azurico Brilliant Blue Low Metal Release Onglaze Colors

Carnival100 Lead-Free Onglaze Colors

CerDeChromAdvanz Four-Color Printing Lead-Free Onglaze Colors

CerDeChromAdvanz Four-Color Printing Low Metal Release Onglaze Colors

CerDeChromAdvanz Seven-Color Printing Lead-Free Inglaze Colors

CerDeChromAdvanz Seven-Color Printing Lead-Free Onglaze Colors

CerDeChromAdvanz Seven-Color Printing Low Metal Release Inglaze Colors

CerDeChromAdvanz Seven-Color Printing Low Metal Release Onglaze Colors

Cleaners for Ceramic Decoration

Fixatives for Undeglaze and Onglaze Ceramic Decoration
